Baicells Nova243: 3.5GHz 10W Band 42/43 LTE Outdoor Base Station
The Baicells Nova243 is an outdoor LTE TDD base station (eNodeB) designed for private network deployments across Bands 41, 42, 43, and 48. With dual 10W output power and 2x2 MIMO, it delivers stable LTE coverage in lightly populated or hard-to-reach areas. Weighing under 25 lbs and built to IP67 standards, it’s well-suited for outdoor installations where durability and ease of deployment are critical.
The Nova243 supports up to 96 concurrent users and offers GUI-based local or remote management. It can operate with an external EPC or Baicells' embedded HaloB core, and supports common backhaul configurations including IPsec.
Available in band-specific variants. This model supports Band 42 and 43.
Deployment Requirements
To deploy the Nova243, you’ll need:
- SAS registration: Only required for CBRS Band 48 deployments.
- IP backhaul: Public or private, with IPSec if required.
- EPC or core network: Cloud-hosted, local, or embedded via HaloB.
- Power and mounting: Standard bracket kit and power supply included. Site power and mounting hardware (pole or wall) to be provided.
- GPS antenna for synchronization: Included. We can provide upgraded outdoor GPS antennas for longer cable runs or poor signal conditions.
Standing up a private network can get involved — from hardware selection and integration, to network design, software configuration, and user device onboarding. Our team of experts can help deliver a complete solution, whether you’re looking for just the parts or a full turnkey deployment. Reach out here to get started.
Key Features
- Supports LTE Bands 42 and 43 (3.5 GHz) with TDD operation and 10 or 20 MHz channel bandwidth.
- Delivers 2x10W (40 dBm) output power with 2x2 MIMO for extended outdoor coverage. Connectorized antenna ports support directional or omnidirectional antennas.
- Supports up to 96 active users per sector, suitable for fixed wireless and lightly loaded mobility deployments.
- Compatible with external EPCs or Baicells’ embedded HaloB core.
- Remote and local management via web UI and TR-069.
- Includes IPsec support for secure public or private backhaul.
- IP67-rated enclosure for weather-resistant outdoor installation.
- Compact, lightweight form factor under 25 lbs.
Kit Contents
- Baicells Nova243 (Band 42/43 variant)
- Mounting bracket kit
- 48V power supply
- Amphenol power plug
- AC US power cable with bare wire end
- GPS antenna
- GPS surge protector
- Two rolls of rubber waterproof tape
- Electrical tape
We can customize this kit to fit your exact needs. Reach out to our expert team here or email us at [email protected].
